FIOCCHETTI EMOTECA 200 ECT-F TOUCH

Temperature Range: +4°C
Capacity: 221 lt (7,81 cu ft)
Blood bags capacity: 120
External Dimensions (W x D x H) cm 60 x 65,5 x 146
Internal Dimensions (W x D x H) cm 50 x 49,6 x 90; Weight Kg 90
Structure and Insulation: sanitized pre-coated steel with bacteriostatic activity, white colour- in/out (rust- corrosion-proof material), or stainless steel 18/10 AISI 304 inside and sanitized pre-coated steel white colour- outside; insulation polyurethane thickness 40 mm
Door: Nr 1 glass door with triple glass panels
Light: Led type with adjustable brightness
Electric Digital Key Lock
Internal equipment: nr.4 extractible aluminum drawers mounted on telescopic slides
Controller: ECT-F TOUCH + DMLP TOUCH DIGITAL MONITOR

ECT-F TOUCH CONTROLLER + independent system DMLP DIGITAL MONITOR TOUCH: recording and alarms and alarm system, with battery back-up.New controller with TFT 7’’ touch screen display easily readable from the distance, with a real time graphic of temperatures and of other selected functions always visible from the home page.

• Temperature recording of the last 10 years
• Acoustic and visual alarm system for temperature deviations, open door, power failure, condenser, and faulty conditions.
• Safety thermostat against freezing and overheating.
• SD card with frontal access: it can store 10 years data recording and relevant documents such as manuals, list of spare parts, videos regarding installation and most common operations.
• USB port that allows to download data directly from the front panel.
• Multimedia section with Tutorial area for instruction movies, service manuals, electrical drawnings, etc.
• Dry contact for remote connection.
• RJ45 port for LAN/Ethernet.
• Password for the turning on and off of the machine, to protect from unauthorized users.

• Integrated Web Server. Independent visual/acoustic alarm and recording system (DMLP DIGITAL MONITOR TOUCH), with an accuracy of 0.1°C thanks to the PT100 probe used for temperature detection. The DMLP manages alarms functions and it is fed by standard rechargeable batteries to record temperatures and events in case of power failure (nr.8 Nihm rechargeable batteries type AA of 1.2 Volt, easily replaceable). The data downloading is managed by the software CAPTURE supplied into the SD CARD: thanks to this software, it is possible to produce graphics and tabs of recorded data.

Alarms: Acoustic and Visual for temperature deviations, power failure and faults, with automatic recording even in case the electricity is off
Safety Thermostat
Data and Event recording: 10 years on SD card; 1 year on Flash-memory
Temperature Graph: A customizable real time graphic always visible from the home page
Connectivity: USB-SD-SIM port with frontal access ; external board for Dry Contact and Serial port RJ45
Refrigeration Type:Forced-air, ventilated
Defrost: Automatic with automatic evaporation of the condensate water
Probe for product simulation

In accordance with: 93/42/CE – class IIa regulation, and following modifications
Package: Strong Cardboard on wooden pallet
DIN 58371 conformity

Accessories (on demand option):

• Blind doors
• Plexiglas front for drawers
• White coated sheet shelf
• Cable port mm 35 with cap
• Cable port mm 15
• Humidity Sensor
• PT100 probe (free contacts)
• Voltage stabilizer
• 4-20mA converter module
• 60 Hz Frequency
• 115 V
• Wooden crate Package

Cijena: 30.521,48 kn + PDV
